HOW TO OPEN THE CRATE

Opening the crate can be easy with the right tools:

• Thin tip flat head screwdriver
• Pliers
• This video!

Where is the serial number?

REGISTER YOUR WARRANTY

When registering your warranty you can simply scan the QR code on top right of the Rhino. This brings you to our website page to fill out your warranty form.

1. The serial number is long alpha-numeric string found on the sticker near the POWER button on you Rhino.
2. You can take a screenshot of your order confirmation email or enter your dealer name, amazon order number, or wherever you made your purchase

12V Reducer Explained

Michael explains how its hooked up, what its for, and why you need it in this quick 2 min video.

How to identify your wires...

Learn how to find your main positive and main negative terminals on your lead acids, and identify your 12v accessories to go to your Rhino 12v reducer.

Watch this first! Any Model cart

REMOVING LEAD-ACIDS

Watch this video to see how to remove your old lead-acids. Get some helpful tips and knowhow before you start:

1. TAKE A PHOTO OF YOUR LEAD-ACID BATTERIES AND WIRING BEFORE YOU REMOVE THEM
2. Bundle your MAIN POS and wires together with electrical tape. Repeat for MAIN NEG wires.
3. Identify any smaller 12V accessory wires connected to your lead-acids (these are your lights etc that will need to connect to the output of your 12V reducer)

EZ-GO RXV

Check out this RXV install for helpfull tips and knowledge before you start. Here's key things to watch:

1. Be sure to watch the blue trigger wire from our 12v reducer go to the solenoid
2. Antother blue wire with black clip from old charge port MUST BE clipped and ran to Rhino positive-this bypasses the computer to say the cart "is not charging" so it will go fwd/reverse
3. Watch how we mount the brackets - they will not sit flush but will fit perfect in the slots and bolts will secure the Rhino tightly

EZ-GO TXT INSTALLATION

Check out our florida dealer Eric Bohannon install our 48v 105ah in a TXT. Some highlights are:

1. Complete unboxing to see what our kit comes with
2. Cleaning tray and grinding down steel tabs for better placement
3. Hooking up the 12v reducer to a fuse block and running the trigger wire to the ignition switch

Club Car Precedent Installation

Watch how to install your Rhino on the passanger side of your cart, with an overview of your charger and LCD installation in the battery tray.

Precedent - How to remove old charge port

Watch this video for tips on removing your old Club Car charge port.

• Requires appropriate screw bit to remove (7)- T40 Torx screws and (3) T30 Torx screws
• Removing these allows to replace the old charge port with our charge port and also to lift the floor matt to run the LCD cable to the dashboard if desired

EZGO CHARGE PORT WIRE

Your EZ-GO cart will not drive without clipping this blue wire from old charge port and running back to the Rhino main positive. Watch this 60sec video to get this simple tip done right...

LCD screen explained!

Short video showing all 3 pages of the LCD screen battery gauge from Founder & CEO Michael McDonald.

ANTI-THEFT EXPLAINED

LOCK STATUS

When you use ANTI-THEFT in the Rhino App it gives the ability to shut off discharge of the battery which switches status to LOCK. Your cart will not drive, but also the battery cannot charge. You can also turn discharge OFF/ON on the LCD screen to overide this with the DSG switch on page 2 of the screen.

Where to put 12V Reducer in EZGO RXV

12V Reducer Trigger Wire in RXV

In most cart models the blue trigger wire on our 12V Reducer goes to the key ignition so that when the key is turned on the 12v converter turns on to power accessories. However in the EZGO RXV it goes to the solenoid in the battery tray, watch this video to see where it goes on the solenoid...

Lead-acid wire tutorial

IDENTIFYING YOUR WIRES

Switching to Lithium Rhino can be quick and easy and identifying your main pos/neg wires on your lead-acid batteries is an important first step along with the 12v wires of your accessories. Watch Trent discuss how do accomplish this with a few methods.
